Description:

SE models offer additional comfort and convenience features: auto manual PTO, telescoping rear hitch, rear hydraulic remotes, tilt steering, premium seat, and rubber floor mat.

Features:

Eco-Friendly Diesel Engine

The whisper-quiet, eco-friendly KIOTI Tier 4 CRDI engine improves fuel efficiency while reducing noise levels. Letting you conquer every task with quiet confidence.

Powerful Hydrostatic Transmission (HST Models)

Hydrostatic transmission for effortless control, twin pedals for intuitive forward and reverse movements, seamlessly adjusting speed without ever touching a clutch.

Single Lever Joystick

The single lever joystick redefines front-loader operation. With a flick of your wrist, you command every movement, from raising the boom to lowering the bucket. A float position allows the bucket free flotation over the ground surface.

3-Point Control Lever (Cab Models)

Allows you to raise and lower your implements with the slide of a lever with minimal effort yet maximum precision. Handily located lever eliminates the need for climbing and contorting, to attach or detach an implement.

High Ground Clearance

The impressive 13.4" ground clearance lets you glide over rocks and uneven ground to conquer any terrain with confidence.

Factory Installed Cab (Cab Models)

The deluxe factory-installed full size cab with air conditioning and heat lets operators perform tasks comfortably in any weather condition.

Specifications:

Engine

• Model: 3H-TM4B
• Manufacturer: KIOTI
• Power: 34.90 hp (26 kW)
• Displacement: 111.40 cu. in. (1,826 cc)
• RPM: 2,600 rpm
• Fuel Type: Diesel
• Aspiration: Intercooler
• Fuel Capacity: 9 gal (34 L)

Transmission

• Transmission Type: Hydrostatic
• Shuttle: Hydrostatic
• Travel Speeds Forward: 3 Ranges with Infinite Speeds
• Travel Speeds Reverse: 3 Ranges with Infinite Speeds
• Travel Speeds Minimum Speed: 0 mph (0 km/h)
• Travel Speeds Maximum Speed: 14.88 mph (23.94 km/h)
• Travel Speeds Min Reverse Speed: 0 mph (0 km/h)
• Travel Speeds Max Reverse Speed: 16.76 mph (27.00 km/h)

PTO (Power Take-Off)

• PTO Type: Independent
• PTO Power: 30.90 hp (23 kW)
• Rear Speed: 540 rpm
• Mid Speed: 2,000 rpm (Optional)

Drive Train

• Brakes: Wet Disc Type
• Clutch: None
• Steering: Hydrostatic Power Steering

Hydraulics

• Pump: Gear
• Pump Capacity: 11.30 gpm (42.90 lpm)
• Lift Capacity: 1,631 lb (740 kg)

Hitch

• Type: Three Point
• Category: Category 1
• Control Type: Position
• Lift Capacity: 1,500 lb (680 kg)

Dimensions

• Width: 54.50 in (1,385 mm)
• Height: 92.90 in (2,360 mm)
• Wheelbase: 65.70 in (1,670 mm)
• Ground Clearance: 13.40 in (340 mm)
• Front Tread: 48.20 in (1,225 mm)
• Rear Tread: 47.60 in (1,210 mm)
• Turning Radius: 8.96 ft (2.73 m)
• Weight: 2,921 lb (1,325 kg)
• Length with Hitch: 120.90 in (3,070 mm)
